In Geenhouse
WB3643 Sumirain 50H-200
Maximum 16 m*200 m (W*L) of irrigation coverage by connecting two tubes.
Largest coverage of all sumisansui products.
Largest coverage of all sumisansui products.
- It is designed to keep its irrigation performance extending up to 200 meters by connecting two tubes.
- It irrigates 8 meters to both sides from the irrigation tube at 0.25 MPa in a windless condition.
- Sumirain is made of thickest special black polyethylene of all Sumisansui, which has excellent durability for long term use.
Use
- All kinds of open field crops from seeding to young plant stage
- Low height crops such as leaf vegetables and root vegetables
- Turfs such as sport grounds and gardens
Precaution
- Lay down the irrigation tube flatly.
- Operate irrigation under appropriate pressure.
- Install a filtration system to prevent spray holes from clogging.
- Filter recommendation: Over 80 mesh
Product Details
Specification
| Material | Polyethylene |
|---|---|
| Product of Origin | Japan |
| Length (meter/roll) | 100 |
| Packing (rolls/box) | 1 |
| Box size (in cm, LWH) | 53*53*12 |
| Box weight (kg) | 14.5 |
| On a pallet (rolls/pallet) | 40 |
|---|---|
| Tube width (in mm, flattened) | 92 |
| Tube diameter (mmφ) | 52 |
| Recommended filtration (#mesh) | 80 |
| Type of fittings | RAIN |
Irrigation performance and water flow rate per pressure
| Operation pressure (MPa) | 0.25 | 0.2 | 0.15 |
|---|---|---|---|
| Coverage: Max. Length (m) | 200 | 200 | 200 |
| Coverage: Width (m) | 16 | 15 | 13 |
| Recommended tube Interval for placing multiple tubes (m) | 12.8 | 12.0 | 10.4 |
| Average precipitation rate (mm/h) | 6.3 | 6.0 | 6.0 |
| Average flow rate (Litter/min·m) | 1.35 | 1.21 | 1.05 |
| Flow rate at 20m (Litter/min·m) | 1.36 | 1.21 | 1.05 |
| Flow rate at 40m (Litter/min·m) | 1.36 | 1.21 | 1.05 |
| Flow rate at 60m (Litter/min·m) | 1.36 | 1.22 | 1.05 |
| Flow rate at 80m (Litter/min·m) | 1.36 | 1.21 | 1.05 |
| Flow rate at 100m (Litter/min·m) | 1.36 | 1.21 | 1.05 |
| Flow rate at 120m (Litter/min·m) | 1.35 | 1.21 | 1.05 |
| Flow rate at 140m (Litter/min·m) | 1.35 | 1.21 | 1.04 |
| Flow rate at 160m (Litter/min·m) | 1.34 | 1.20 | 1.04 |
| Flow rate at 180m (Litter/min·m) | 1.34 | 1.19 | 1.03 |
| Flow rate at 200m (Litter/min·m) | 1.33 | 1.19 | 1.03 |
