In Open field
WK1016 Sumisansui MarkⅢ
The MarkⅢ with “Over 45 degrees” spray angle nicely irrigates small to middle height crops.
- “Over 45 degrees” spray angle is usable for middle height crops.
- It irrigates 2.5 meters to both sides from the irrigation tube at 0.08 MPa in a windless condition.
- Irrigation performance is highly uniform from the beginning of the tube up to 100 meters.
- Made of special black polyethylene with high durability against sunlight.
- The light weight & compact product isn't only for professional farming but also for hobby gardens.
Use
- All kinds of open field crops from seeding to young plant stage
- Low to middle height crops such as leaf vegetables and root vegetables
- Turfs such as sport grounds and gardens
Precaution
- Lay down the irrigation tube flatly.
- Operate irrigation under appropriate pressure.
- Install a filtration system to prevent spray holes from clogging.
- Filter recommendation: Over 80 mesh
Product Details
Specification
| Material | Polyethylene |
|---|---|
| Product of Origin | Japan |
| Length (meter/roll) | 100 |
| Packing (rolls/box) | 5 |
| Box size (in cm, LWH) | 27*26.5*30.5 |
| Box weight (kg) | 12.0 |
| On a pallet (rolls/pallet) | 240 |
|---|---|
| Tube width (in mm, flattened) | 50 |
| Tube diameter (mmφ) | 28 |
| Recommended filtration (#mesh) | 80 |
| Type of fittings | M |
Irrigation performance and water flow rate per pressure
| Operation pressure (MPa) | 0.08 | 0.04 |
|---|---|---|
| Coverage: Max. Length (m) | 100 | 100 |
| Coverage: Width (m) | 5 | 4.8 |
| Recommended tube Interval for placing multiple tubes (m) | 4.0 | 3.8 |
| Average precipitation rate (mm/h) | 6.6 | 5.9 |
| Average flow rate (Litter/min·m) | 0.55 | 0.38 |
| Flow rate at 20m (Litter/min·m) | 0.59 | 0.41 |
| Flow rate at 40m (Litter/min·m) | 0.59 | 0.40 |
| Flow rate at 60m (Litter/min·m) | 0.55 | 0.38 |
| Flow rate at 80m (Litter/min·m) | 0.52 | 0.36 |
| Flow rate at 100m (Litter/min·m) | 0.49 | 0.34 |
